Mazak CV5-500
Bridge construction 5-axis vertical machining center with a fully supported trunnion table provides high-rigidity for high-accuracy machining. High-accuracy simultaneous 5-axis machining center.
Designed to deliver high speed, high-accuracy machining and ease of operation. The CV5-500 defines a new standard for 5-axis machining offering exceptional value.
-
Fully supported trunnion table with roller gear cam on B/C axes and roller linear guides on X-, Y- and Z-axes
-
High-rigidity 18,000 min-1 spindle 18.5kW/119.4Nm (10% ED rating) with an optional 18,000 min-1 high-speed spindle.
-
48 tool magazine with high-speed ATC (1.3 seconds tool-to-tool)
-
Minimised footprint with side chip conveyor
-
High-performance MAZATROL SmoothX CNC delivers exceptional 5-axis machining results.
![VTC-800_30SR_SmoothX_800-600jp[10670].png](https://static.wixstatic.com/media/a5131c_f62c14d4570b47d7ad9f6da9fe5a90b2~mv2.png/v1/fill/w_420,h_315,al_c,q_85,usm_0.66_1.00_0.01,enc_avif,quality_auto/VTC-800_30SR_SmoothX_800-600jp%5B10670%5D.png)
Mazak VTC800/30SR
CAPACITY Table working surface (Length) 3,500 mm
Table working surface (Width) 820 mm
Saddle (longitudinal) X-axis 3,000 mm
Column (cross) Y-axis 800 mm
Spindle head (vertical travel) Z-axis720 mm
SPINDLE HEAD Spindle speed maximum (standard)18,000 min-¹
FEED RATES Rapid traverse (X-axis)50 m/min
Rapid traverse (Y-axis) 50 m/min
Rapid traverse (Z-axis) 50 m/min
TABLE Table length dimension 3,500 mm
Table width dimension 820 mm
AUTOMATIC TOOL CHANGER Tool storage capacity (standard)30 tools
Tool shank CAT-40/ MAS BT-40
MACHINE DIMENSIONS Machine width 5,250 mm
Machine depth 4,046 mm
XYZ 1510 HD VMC With 4th Axis
1500mm ‘X’ travel on this solid cast machine, with a hunger for metal removal.
23HP / 17kW SPINDLE
1600 x 600 mm TABLE
1500 x 600 x 600 mm TRAVEL
8000 RPM SPINDLE
SOLID CASTING 9000 KG
X travel 1500 mm
Y travel 600 mm
Z travel 600 mm
Cutting feed rates 1-16000mm/min
Spindle speed 5 – 10000 rpm
Tool magazine capacity 24 arm type
Tool change time tool to tool 2.5 sec
Max tool diameter 100 mm
Max tool weight 7 Kg
Coolant capacity 200 L
3 off XYZ MINI MILL
XYZ MINI MILL 560 Optimise the profitability of a small space with this top selling VMC. Not to be confused with the competitors lighter less robust attempts at the Mini Mill. The 560 is at the top of its class with power and performance in abundance. 15 HP SPINDLE 610 x 370 mm TABLE 560 x 400 x 500 mm TRAVEL 8000 RPM SPINDLE SOLID CASTING 3100 KG
HURCO VM30 WITH 4TH AXIS
The VM30 is a legitimate 50" X-travel machine. It's ideal for manufacturing long parts while not demanding excessive floor space.
It is a solidly built, one-piece machine base that comes standard with a 40 taper, 10,000 RPM spindle. It also has a 20-pocket, swing-arm tool changer.
It comes standard with Hurco’s Max control, making it one of the most flexible machines on the market.
XYZ MINI MILL 560 with 4th Axis
Optimise the profitability of a small space with this top selling VMC. Not to be confused with the competitors lighter less robust attempts at the Mini Mill. The 560 is at the top of its class with power and performance in abundance.
15 HP SPINDLE
610 x 370 mm TABLE
560 x 400 x 500 mm TRAVEL
8000 RPM SPINDLE
SOLID CASTING 3100 KG
![VMX24WinMax_global[1].jpg](https://static.wixstatic.com/media/a5131c_97310016ec68499891801faebccc84d5~mv2.jpg/v1/fill/w_342,h_307,al_c,q_80,usm_0.66_1.00_0.01,enc_avif,quality_auto/VMX24WinMax_global%5B1%5D.jpg)
HURCO VMX24
Not many machining centers in the world with a 24” X-axis travel that have as small a footprint (85.8 x 91") as the Hurco VMX24. Even fewer with an accompanying 20” Y-axis travel. Then, packaged with all the additional features, it certainly stands alone.
XYZ PRO1500
Spindle Drive Motor 2.25 kw (3 hp)
Ram travel 450 mm
Vari Speed Range High/Low 60-4200 rpm
Spindle taper R8
Table Size 1270 x 254 mm
Quill power feeds .038 .076 .15 mm
T slots-3 15.9 mm 3 off
Quill travel 127 mm
Longitudinal travel - X axis 750 mm
Quill diameter 86 mm
Cross travel - Y axis 380 mm
Max table load 350 kg
Knee vertical travel - Z axis 400 mm
Swivel on turret 360°
Slide type Hardened Way
Head tilt front to back 45°-45°
Head tilt left to right 90°-90°
Net weight approx 1250 kg
Max throat depth 686 mm
XYZ PRO3000
Spindle Drive Motor 3.75kw (5 HP)
Ram travel 450 mm
Vari Speed Range High/Low 70-3600 rpm
Spindle taper 40 ISO
Table Size 1371 x 305 mm
Quill power feeds .038 .076 .15 mm
T slots-3 15.9 mm 3 off
Quill travel 127 mm
Longitudinal travel - X axis 780 mm
Quill diameter 105 mm
Cross travel - Y axis 410 mm
Max table load 550 kg
Knee vertical travel - Z axis 400 mm
Swivel on turret 360°
Slide type Hardened Box Way
Head tilt front to back 45°-45°
Head tilt left to right 90°-90°
Net weight approx 1650 kg
Max throat depth 700 mm
XYZ PRO4000
Spindle Drive Motor 5.75 Kw (7.5HP)
Spindle taper 40 ISO
Programable speed range 40-5000 rpm
Quill power feeds .038 .076 .15 mm
2 Speed ranges Standard
Quill travel 140 mm
Table size 4742 x 356mm
Quill diameter 116 mm
T slots-4 15.9 mm 4 off
Max table load 850 kg
Longitudinal travel X axis1016 mm
Head tilt left to right 45°-45°
Cross travel Y axis 596 mm
Throat depth 610 mm
Head vertical travel Z axis 540 mm
Net weight approx 2750 kg
XYZ PRO5000
Give yourself an advantage! How many companies do you know with 1500mm capacity on a relatively low cost CNC Bed Mill.
7.5HP VARIABLE SPEED HEAD 76” x 14” (1930 x 356mm ) TABLE 60” x 23 1/2” x 23” (1524 x 596 x 540mm) TRAVEL PROGRAMMABLE 5000 RPM SPINDLE Guards removed for clarity
Spindle Drive Motor 5.75 Kw (7.5HP)
Programable speed range 40-5000 rpm
2 Speed ranges Standard
Table size 1930 x 356mm
T slots-4 15.9 mm 4 off
Longitudinal travel X axis 1524 mm
Cross travel Y axis 596 mm
Head vertical travel Z axis 540 mm
Spindle taper 40 ISO
Quill power feeds .038 .076 .15 mm
Quill travel 140 mm
Quill diameter 116 mm
Max table load 850 kg
Head tilt left to right 45°-45°
Throat depth 610 mm
Net weight approx 3100 kg
